The LD-4500XD DumpMaster is designed to dump practically all existing postal equipment. Listed below are examples of the equipment it dumps.
This unit dumps the following types of equipment:
| WEST-PAK pallet containers | 4' cardboard boxes |
| General purpose containers | pallets of mail |
| All-purpose containers | BMC wire containers |
| 1046 hampers | BMC-over the road containers |
| 1033 hampers (2 at a time) | 1075 U-cart (2 at a time) |
| 6' cardboard boxes |
Safety
The LD-4500XD has safety screens on both sides, and environmental self adjusting alram that operates both on the op and down cycle and limit switches on both the up and down cycles.
General Info & Specs.
| Pivot Bearing | McGill Pivot Bearing |
| Cylinder | 2-3" x 20" stroke |
| Dump cycle | 40 seconds |
| Chute size | Funneling to 38" (54" x 63" x 86") |
| Moveability | Portable or anchored |
| Capacity | 5000 lbs |
| Dump height | 34" |
| Dump angle | 35° |
| Finish | Enamel |
| chute contruction | Welded steel |
| Safety Screen | wire mesh (2) |
| MFG Warranty | 1 year; parts only |
Electrical Systems
| Enclosure | Nema 12 |
| Primary Voltage | 208V 3PH |
| Motor | 3HP |
| Starter | Siemens 3TF and fuse transformer |
| Limit Switch | Micro switch/LS3 N.C. |
| Control | 2 button station 2 button single contact |
| Sensor | Sunx EQ - 34 |
Hydraulic Systems
| Pump | 3 GPM mounted to motor |
| Valve | Single acting dump valve |
Warranty - 6 months warranty, parts only or major repairs.
